Description

coolant temperature – Standard 2-1/16″ size – 120°-260° – Black Face – Black BezelPlug and play compatibility with all Terminator, HP, and Dominator ECUâ??s (w/ module P/N 554-130)No programming necessary eliminates the need to install duplicate sending unitsCompatible with all Holley EFI touch screens, dashes, handheld tuners, and other CAN devices270° sweep pointer from 6 to 3 oâ??clock makes gauges easy to read at a glancePointer is driven by a high-torque internal stepper motor to ensure accurate movement in racing conditionsAdjustable LED warning light allows user to set both low and high trigger pointsLED warning light brightness can be configured for both day and nightPeak recall lets user view the min/max gauge readings with the push of a buttonSpin lock ring threads to back of gauge case for simple and secure gauge mountingCNC machined billet aluminum bezels with anodized finish â?? Bezels are threaded for easy replacementMultiple bezel options available separately â?? User can customize the gauges to their preferenceGauges include 6 in. daisy chain cable and 3 ft. power harnessAdditional length cables and multi-connection power distribution harness available separatelyThese analog-style gauges are designed specifically for use with Holley EFI systems. They are compatible with all Terminator, HP, and Dominator ECU’s, allowing them to be installed in a variety of Holley EFI equipped vehicles. CAN-bus communication allows the gauges to daisy chain using the included stereo cables, making installation quick and clean. The required gauge module (P/N 554-130) allows plug and play communication between the ECU and gauges, through a one-wire ECU connection.

Bezel Color: Black

Bezel Material: Aluminum

Body Color: Black

Color Change Button: No

Dimmable: No

Display Type: Analog

Face Color: Black

Face Diameter: 2-1/16″

Face Shape: Round

Gauge Background Color: Black

Gauge Type: Coolant Temperature

Grade Type: Performance

Illuminated: Yes

Indicator Markings Color: Multiple Colors

Lens Color: Clear

Liquid Filled: No

Maximum Temperature Reading: 260 FA

Minimum Temperature Reading: 120 FA

Mounting Hardware Included: Yes

Mounting Pod Included: No

Pointer Color: Red

Sensor Included: No

Sensor Type: Electrical

Size: 2-1/16″

Type: Electrical

Universal Or Specific Fit: Universal

Warning Light: Yes
