Description

Sniper EFI Universal Fuel Tank System 255 LPHHolley and Sniper will help you to complete your EFI swap with our new EFI Conversion Fuel Tanks. The kit includes the tank, a 255 lph fuel pump, internal baffling, a fuel level sender, and the filler neck. The tank is powder coated for corrosion resistance and great looks. These tank kits are a complete solution for your EFI project!Supports up to 550 EFI (@ 60 PSI at 13.5 Volts / 10.4 AMP Draw)Size: 27-3/4″ x 17-3/4″ x 8-1/2″***Two straps 42″ length by 1 3/8″ width***Gas cap and filler neck not includedThese universal tanks are perfect for your next classic truck EFI conversion project.When installing sending units, please remember to rotate the unit until the mounting holes align with the flange holes in the tank.

Application: Universal

Attached Sump: Yes

Baffled Sump: Yes

Color: Silver

Drain Plug: No

Filler Neck Attached: No

Finish: Powdercoated

Free Flow LPH: 255

Fuel Sending Unit Ohms: 0-90 Ohms

Fuel System Compatibility: Electronic Fuel Injection

Fuel System Type: Gasoline

Fuel Tank Coating: Powder Coated

Gallon Capacity: 16

Grade Type: Performance

Lock Ring Included: Yes

Material: Steel

Maximum Flow Rating: 255 LPH

Mounting Straps Included: Yes

New Straps Included: Yes

O-Ring Included: Yes

Resistance Ohms Empty: 0 82

Resistance Ohms Full: 90 82

Sending Unit Included: Yes

Tank Capacity: 16 GA

Tank Color: Gray

Tank Material: Steel
