Description
Sniper EFI Sheet Metal Fabricated Intake Manifold GM LS1/2/6Holley is now offering budget friendly fabricated intake manifolds for LS, Small Block Chevy and Small Block Ford engines in carbureted and EFI versions!*** This intake is designed to work with stock LS heads. The use of some aftermarket cylinder heads may result in port misalignment ***
Basic Operating RPM Range: 2500-7000 RPM
Carburetor Flange: Square/4150
Carburetor Quantity: 1
Carburetor Studs Included: No
CNC Ported: No
Color: Silver
Construction: Fabricated
Cylinder Head Port Shape: Cathedral
Deck Height: 9.24 Inch
EGR Port: No
Engine: GM LS1/LS2/LS6
Flange Size: 4150
Flange Style: 4150 Square Bore
Front Maximum Height: 8.858″
Fuel Injectors Included: No
Fuel Rail(s) Included: Yes
Fuel System Type: EFI
Gasket Or Seal Included: Yes
Grade Type: Performance
Injector Style Provision: EV1
Intake Port Gasket(s) Included: Yes
Manifold Type: Fabricated
Material: Aluminum
Nitrous Bung(s) Included: No
Plenum Finish: Polished
Rear Maximum Height: 8.858 Inch
Recommended Use: Forced Induction
Removable Runners: No
Removable Top/Lid: No
Runner Length: 4.921″ (125mm)
Single Or Dual Plane Type: Single Plane
Style: EFI
Throttle Body Bore Diameter: 3.6 MM
Throttle Body Gasket Included: No
Throttle Body Included: No
Throttle Bore: 4150 flange
Vacuum Ports: (3) 1/8″-28BSPT & (1) 1/4″-19BSPT
